MOUTH DISSOLVING FILM SLITTING

Product code: USLT-200

Umang Pharmatech Pvt Ltd’ s USLT-300 is a film Slitting machine designed to slit the mother film to child lm coils as per the required width. The entire slitting chamber is visible from outside.
Lets Understand the Process :-
The mother film coil is mounted on the unwinding roll, empty roll reel is assembled on child film winding roll and to lay and connect through the slitting station. Activate the machine. The mother film coil will be released from the unwinding roll by pulling action of winding rolls. The mother film coil moves through slitting station. At slitting station mother coil film will be slit in to pre-determined width by slitting blades. These slits will be wound on different child coil rolls.

Special Features

Built in electrical / HMI panel.
Cantilever Design Roller for Holding & pulling roller for smooth movement of mother lm roll.
Top slitting roller with high shear blades.
Child coil Reel holding rolls with clutch gear arrangements

Advantages

Top slitting roller with high shear blades to slit the mother film into different child films of width as required.
Mother film coil unwinding station with pneumatic brake control
Child coil winding station.
Pulling system
